The UnitedSeats MGV84/C1 is a mechanical suspension seat suitable for small agricultural vehicles, (narrow gauge) tractors and compact construction machinery. The seat has a narrow suspension system that is easily adjustable for weight (50-130kg).

Type
Mechanical suspended seat
Suspension travel
80 - 100 mm
Weight range
50 - 125 kg
Weight adjustment
Manual
Climate System
Slide rail travel in cm
18
Seat upper
C1
Suspension nr.
MGV84
Slide rail
Height adjustment
Mechanical
Horizontal suspension
Seat depth adjustment
Seat tilt adjustment
Headrest
Backrest extension
Armrest
Both
Contact switch
Belt
Lumbar support
Mechanically adjustable
Backrest adjustment
Horizontal suspension sideways
Shoulder Adjustment
Control Handles
Left + frontside
Turntable
Joystick console
Seating height in cm
30
Seat width in cm
50
Mounting width of floor in mm
120
Material cover
Stof
Upholstery color
Black
Upholstery color style
Blended

In addition, standard features include armrests, mechanical height adjustment, mechanical lumbar support and longitudinal adjustment. The back is also adjustable. Equipped with fabric upholstery but optionally available in PVC version.
Article number: US.203240.
